Hi-Flow-PGF-1000-E-60.69

Product Line Description

60.69 Inch (in) Length and 100 Micrometer (µm) Micron Rating Glass Fiber Filter Media Highflow Pleated Filter Cartridge with Ethylene Propylene Diene Monomer (EPDM) Seal Material.

Highflow Pleated Filter Cartridge is single open ended which design for the direction from an inside to outside flow pattern. The large filter area ensure the high dirt holding capacity. The low cost save the number of filter cartridge. Long service life and superior flow rates are the main characteristics. All contaminants can be removed efficiently.

Specifications
Brands JMCC
Model Hi-Flow
Material of Construction
Filter Media Pleated Glass Fiber
Support Layer Polypropylene (PP)
End Adapter Glass Fiber Reinforced Polypropylene
Seal Materials E – Ethylene Propylene Diene Monomer (EPDM)
Micron Rating 100 µm
Filtration Area 1900 L/min
Dimensions
Length 60.69 in
1541 mm
Outside Diameter 6 in
152 mm
Recommended Operating Conditions
Maximum Operating Temperature 121 ºC
Maximum Differential Pressure at 121 Degree Celsius (ºC) Temperature 3.4 bar
Recommended Change Out Differential Pressure at 20 Degree Celsius (ºC) Temperature 2.4 bar
Applications
  • Pre-filtration of RO, pre-treatment of sea water desalination
  • Bottled water, high Fructose, edible oil, soft drinks
  • API, solvents, and water filtration in BioPharma market
  • Paints and coatings, petrochemical, refineries
  • Microelectronics
